NTP-L48 Mounting Brackets on NCS 2015 Shelf for ANSI Rack
Configuration
This procedure helps in mounting the brackets on the
NCS 2015 shelf for ANSI rack configuration. The
mounting brackets can be installed in the middle
position of the chassis.
Purpose
•
#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
•
10 M4 x 6mm flat-head Phillips screws
Tools/Equipment
DLP-L62 Unpacking and Verifying the Shelf , on
page 20
DLP-L63 Inspecting the Shelf, on page 22
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1
Align the mounting bracket screw holes against the shelf screw holes.
Step 2
Insert the screws and tighten them to a torque value of 11.5 in-lb (1.3 N-m).
Step 3
Repeat steps 1 and 2 for the mounting bracket on the opposite side.
