Cisco NCS 2006 User Manual

DLP-L27 Installing Timing Wires on NCS 2006 - ANSI
This task installs the timing cables on the NCS 2006
ECU module for ANSI.
Purpose
Wire-wrap tool and 100-ohm wire-wrap cable.Tools/Equipment
NTP-L8 Install the NCS 2006 ECU and ECU-S
Modules, on page 277
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1
Locate the timing connector on the ECU module (BITS-1 or BITS-2 In/Out). The following figure shows
ECU module wire-wrap pins.
Figure 136: ECU module Wire-wrap Pins
The following table lists the ECU module pin assignments for ANSI.
Cisco NCS 2000 Series Hardware Installation Guide
235
Connecting and Routing the Cables
DLP-L27 Installing Timing Wires on NCS 2006 - ANSI
