This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure
that the protective device is rated not greater than: 10A-20A, 100-240 VAC~. Statement 1005
Warning
A readily accessible two-poled disconnect device must be incorporated in the fixed wiring. Statement
1022
Warning
This unit might have more than one power supply connection; all connections must be removed to
de-energize the unit. Statement 1028
Warning
Always use an ESD wristband when working with a powered NCS 2015. For detailed instructions on how
to wear the ESD wristband, see the Electrostatic Discharge and Grounding Guide for Cisco NCS 2000
Series.
Caution
Procedure
Step 1
Verify that the correct fuse and alarm panel is installed in the top mounting space.
•
For a DC power supply, the fuse rating must not exceed 60 A.
•
For an AC power supply, the fuse rating must not exceed 20A. For North America, the branch circuit
protection must be rated 20A. The overcurrent/short circuit protection must be in accordance with local
and national electrical codes.
Step 2
Connect the office ground to the NCS 2015 shelf. For detailed instructions on grounding, see the Electrostatic
Discharge and Grounding Guide for Cisco NCS 2000 Series .
Step 3
Depending on the shelf and the power module installed, complete the necessary task:
Step 4
Complete the DLP-L80 Turning On and Verifying DC Office Power on the NCS 2015 Shelf, on page 344
Step 5
Continue with NTP-L54 Installing Fan-Tray Assembly in NCS 2015 Shelf, on page 393 .
Stop. You have completed this procedure.
DLP-L81 Connecting Office Power (AC) to the NCS 2015 Shelf
This task connects AC power to the NCS 2015 shelf.Purpose
Cisco NCS 2000 Series Hardware Installation Guide
336
Connecting Power and Ground
DLP-L81 Connecting Office Power (AC) to the NCS 2015 Shelf
