Mounting a Single Node
The NCS 2006 requires 264.16 mm (10.4-inches) minimum of vertical rack space. To ensure the mounting
is secure, use two to three mounting screws for each side of the shelf. A shelf should be mounted at the bottom
of the rack if it is the only unit in the rack.
In an ETSI rack, the brackets are mounted only in the front position.
If the NCS 2006 shelf is fully loaded, then two people should install it. However, it is possible for one person
to install an empty shelf. The shelf should be empty for easier lifting. For information on the NCS 2006 shelf
weight, see the A.3.14 Dimensions section on page A-14.
NTP-L3 Mounting the NCS 2006 Shelf
This procedure helps in mounting the NCS 2006 shelf.Purpose
#2 Phillips Dynamometric screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
ETSI only:
Six M6 x 20 pan-head Phillips mounting
screws
ANSI only:
Six #12-24 x 3/4 pan-head Phillips
mounting screws
Tools/Equipment
DLP-L62 Unpacking and Verifying the Shelf , on
page 20
DLP-L63 Inspecting the Shelf, on page 22
NTP-L2 Mounting the Brackets in ANSI
Configuration , on page 163
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Cisco NCS 2000 Series Hardware Installation Guide
189
Mounting the Cisco NCS 2006 Shelf
Mounting a Single Node
