The following figures show the dimensions of the air plenum relative to the cabinet or rack.
Figure 11: Dimension of Cisco NCS 2002 chassis relative to the air plenum
Figure 12: Dimension of Cisco NCS 2002 chassis relative to the air plenum
Air Plenum Rack and Cabinet Compatibility
The table shows the compatibility of air plenum with the ANSI and ETSI racks and cabinets. The chassis can
be installed with brackets in front position only.
Table 6: Air plenum compatibility with racks and cabinets
Front-to-back air flowRack / Cabinet
Supported
1
ANSI 19-inch rack
Supported
1
ANSI 19-inch cabinet
Cisco NCS 2000 Series Hardware Installation Guide
27
Installing the Air Flow Regulator
Air Plenum Rack and Cabinet Compatibility
