Step 10
Tighten the door screws to a torque value of 6.5 in-lb (0.75 N-m) to close the standard door as shown in the
figure below.
Figure 146: Closing the Standard Door of the NS 2006 Shelf
Stop. You have completed this procedure.
NTP-L5 Opening and Removing the Standard Door of the NCS
2006 Shelf
This procedure opens and removes the standard door
of the NCS 2006 shelf.
Purpose
#2 Phillips Dynamometric screwdriverTools/Equipment
•
NTP-L2 Mounting the Brackets in ANSI
Configuration , on page 163
•
Connect the chassis to the office ground. For
detailed instructions on how to ground the
chassis, see the Electrostatic Discharge and
Grounding Guide for Cisco NCS 2000 Series .
Prerequisite Procedures
RequiredRequired/As Needed
Cisco NCS 2000 Series Hardware Installation Guide
252
Installing the Cisco NCS 2006 Door and Other Modules
NTP-L5 Opening and Removing the Standard Door of the NCS 2006 Shelf
