b
Plug the other end into the MSM port of the NCS 2006 SSC 1 that corresponds to the control card in
Slot 1.
3
Using a cross-over (CAT-5) LAN cable:
a
Plug one connector into the MSM port of the NCS 2006 SSC 1 that corresponds to the control card in
Slot 8.
b
Plug the other end into the P-MSM port of the NCS 2015 SSC 2 that corresponds to the control card
in Slot 17.
4
Using a cross-over (CAT-5) LAN cable:
a
Plug one connector into the M-MSM-1 port of the NCS 2015 SSC 2 that corresponds to the control
card in Slot 1.
b
Plug the other end into the RJ-45 port of the control card in Slot 7 of ONS 15454 SSC 3.
5
Using a cross-over (CAT-5) LAN cable:
a
Plug one connector into the RJ-45 port of the control card in Slot 11 of ONS 15454 SSC 3.
b
Plug the other end into the P-MSM-1 port of the NCS 2015 SSC 4 that corresponds to the control card
in Slot 17.
6
Using a multi-mode fiber optic cable:
a
Plug one connector into the M-MSM-2 port of NCS 2015 SSC 4 that corresponds to the control in Slot
1.
b
Plug the other connector into the M-MSM-2 port of NCS 2015 SSC 5 that corresponds to the control
in Slot 1.
7
Repeat Steps 3 through 6 to connect the remaining SSCs.
8
To complete the ring, plug one connector of a cross-over (CAT-5) LAN cable into P-MSM-1 port of NCS
2015 SSC 15. Plug the other connector into the MSM port of the NCS 2006 NC that corresponds to the
control card in Slot 8.
Scenario 6: Using RJ-45 Ports Connect Cisco ONS 15454 Node Controller, and ONS 15454, NCS
2006, and NCS 2015 Subtending Shelves in a Ring Topology
Usage of TCC3 card as the node controller is recommended.Note
•
Usage of TCC3 card as the node controller is recommended.
•
The maximum number of NCS 2015 shelves that can be subtended is 10.
1
Using a cross-over (CAT-5) LAN cable:
a
Plug one connector into the RJ-45 port of the control card in Slot 7 of the ONS 15454 NC.
Cisco NCS 2000 Series Hardware Installation Guide
437
Multishelf Management
Ring Topology
