Figure 180: Comparison of the Deep Door Extension
Deep door extension of
6.56 inches when a
23-inch standard bracket
is used
2Deep door extension of
4.55 inches when a
23-inch Z-bracket is used
1
Stop. You have completed this procedure.
NTP-L49 Mounting Brackets on NCS 2015 Shelf for ETSI Rack
Configuration
This procedure helps in mounting the brackets on the
NCS 2015 shelf for ETSI rack configuration. The
mounting brackets can be installed in the middle
position of the chassis.
Purpose
Cisco NCS 2000 Series Hardware Installation Guide
307
Mounting the Brackets on the NCS 2015 Shelf
NTP-L49 Mounting Brackets on NCS 2015 Shelf for ETSI Rack Configuration
