Procedure
Step 1
Grip the sides of the SFP with your thumb and forefinger and insert the SFP into the SFP port on the ECU.
Step 2
Slide the SFP through the slot until you hear a click. The click indicates that the SFP is locked into the slot.
Step 3
To connect the multi-mode optical fiber, attach the appropriate optical fiber cable directly to the LC-type
connector of the SFP.
Stop. You have completed this procedure.
NTP-L63 Configure a Cisco Catalyst 3560 (Active and Standby)
for a Multishelf Node
This procedure uses Cisco IOS to configure the Cisco
Catalyst 3560 for a multishelf node configuration.
For more information about the Catalyst 3560, refer
to the Catalyst 3560 product documentation.
Purpose
NoneTools/Equipment
NonePrerequisite Procedures
RequiredRequired/As Needed
Onsite or remoteOnsite/Remote
SuperuserSecurity Level
When Cisco Catalysts are used in a multishelf node configuration, the Cisco Catalysts can be used for
other applications as long as they do not interfere with the VLAN settings of the multishelf node
configuration.
Note
Procedure
Step 1
At the Cisco IOS command line interface (CLI) for the Catalyst switch, enter the following spanning tree
commands:
Example:
Switch(config)#spanning-tree mode rapid-pvst
Cisco NCS 2000 Series Hardware Installation Guide
413
Multishelf Management
NTP-L63 Configure a Cisco Catalyst 3560 (Active and Standby) for a Multishelf Node
