If you removed the door, complete the NTP-L4 Installing the Standard Door of the NCS 2006 Shelf , on page
247.
Stop. You have completed this procedure.
NTP-L59 Replacing Fan-Tray Assembly of NCS 2015 Shelf
Assembly
This procedure replaces the fan-tray assembly of the
NCS 2015 shelf assembly.
Purpose
Small slot-head screwdriverTools/Equipment
NTP-L54 Installing Fan-Tray Assembly in NCS 2015
Shelf, on page 393
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Do not force a fan-tray assembly into place. Doing so can damage either the connectors on the fan tray
or the connectors on the back panel of the shelf assembly, or both.
Caution
The estimated time required to change a fan-tray assembly is 2 minutes.Note
Procedure
Step 1
Open the front door of the shelf assembly (see NTP-L51 Opening and Removing the Door of the NCS 2015
Shelf , on page 381). If the shelf assembly does not have a front door, continue with the next step.
Step 2
Untighten the captive screws on the fan-tray assembly.
Step 3
Extract the fan tray partially using the handle in order to disconnect the backplane connector and wait until
the fan stops.
Step 4
When the fans have stopped, pull the fan-tray assembly completely out of the shelf assembly.
Step 5
Slide the new fan-tray into the shelf assembly until the electrical plug at the rear of the tray plugs into the
corresponding receptacle on the backplane.
Step 6
Swing the door closed and turn the knob to lock.
Stop. You have completed this procedure.
Cisco NCS 2000 Series Hardware Installation Guide
460
Maintaining the NCS 2002, NCS 2006, and NCS 2015 Shelves
NTP-L59 Replacing Fan-Tray Assembly of NCS 2015 Shelf Assembly
