Some wire-wrap tools require a minimum of 24 AWG wires to prevent breakage. Ensure that the
SCSI alarm wire-wrap cable is used for 24 AWG wires. When the SCSI alarm wire-wrap cable is
used, the number of alarms is reduced as fewer strands of wire are supported compared to the SCSI
alarm and SCSI alarm patch cables. Table 5-5 lists alarm connector pin details for SCSI alarm
wire-wrap cable.
Note
Stop. You have completed this procedure.
DLP-L26 Installing Alarm Wires in NCS 2006
This task installs alarm cables on the ECU module of
the NCS 2006 to provision external (environmental)
alarms and controls.
Purpose
Alarm SCSI 26-pin cable
Wire-wrap tool for BITS
Screw for the alarm cable
Tools/Equipment
NTP-L8 Install the NCS 2006 ECU and ECU-S
Modules, on page 277
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Step 1
Connect one end of the SCSI cable to the input alarms or input/output alarms, and the other end to the alarm
source (See Diagram 1 of the figures below ).
These alarms are generic signals that the operator assigns to a definite wire (color) and name through
the Craft Terminal.
Note
Cisco NCS 2000 Series Hardware Installation Guide
230
Connecting and Routing the Cables
DLP-L26 Installing Alarm Wires in NCS 2006
