NTP-L56 Attaching Wires to Alarm, Timing, LAN, and Craft Pin
Connections
Use this procedure to attach alarm, timing, LAN, and
craft wires in the NCS 2015 shelf.
Purpose
Twisted #22 or #24 AWG (0.51 mm² or 0.64 mm²)
shielded wires for LAN or craft 75-ohm coaxial cable
with DIN-1.0/2.3 miniature coaxial connector, Alarm
26 pins SCSI cable.
Tools/Equipment
NonePrerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Always use the supplied ESD wristband when working with a powered NCS 2006. For detailed instructions
on how to wear the ESD wristband, see the Electrostatic Discharge and Grounding Guide for Cisco NCS
2000 Series.
Caution
Procedure
Step 1
Complete DLP-L76 Installing Alarm Wires in NCS 2015, on page 350 if you are provisioning external alarms.
Step 2
Complete DLP-L77 Installing Timing Wires on NCS 2015, on page 352 if you are provisioning external
timing.
Step 3
Complete DLP-L78 Installing LAN Wires in NCS 2015, on page 356 to create an external LAN connection.
Stop. You have completed this procedure.
DLP-L76 Installing Alarm Wires in NCS 2015
This task installs alarm cables on the power input
panel of the NCS 2015 shelf to provision external
(environmental) alarms and controls.
Purpose
Cisco NCS 2000 Series Hardware Installation Guide
350
Connecting and Routing the Cables
NTP-L56 Attaching Wires to Alarm, Timing, LAN, and Craft Pin Connections
