connections between the NC and SSC can be done using RJ-45 ports, SFP ports, or both. The MSM cable
connections can be created between two M-MSM-x ports or two P-MSM-x ports.
VoIP or UDC
VoIP or UDC is an RJ45 port that can be configured to support UDC or VoIP service on an NCS 2015 shelf.
There are two VoIP or UDC ports on the NCS 2015 ECU module. The UDC/VoIP-1 port is connected to the
TNCS card in Slot 1 and the UDC/VoIP-2 port is connected to the TNCS card in Slot 17. The VoIP or UDC
port also supports Power over Ethernet for connecting VoIP equipments.
NTP-L52 Install NCS 2015 ECU Module
This procedure installs the external connection unit
(ECU) in the NCS 2015 shelf.
Purpose
Small slot-head screwdriverTools/Equipment
•
NTP-L48 Mounting Brackets on NCS 2015
Shelf for ANSI Rack Configuration, on page
303.
•
Connect the chassis to the office ground. For
detailed instructions on how to ground the
chassis, see the Electrostatic Discharge and
Grounding Guide for Cisco NCS 2000 Series .
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
The intra-building port(s) of the equipment or subassembly is suitable for connection to intra-building
or unexposed wiring or cabling only. The intra-building port(s) of the equipment or subassembly
MUST NOT metallically connect to interfaces that connect to the OSP or its wiring. These interfaces
are designed for use as intra-building interfaces only (Type 2 or Type 4 ports as described in
GR-1089-CORE, Issue 5) and require isolation from the exposed OSP cabling. The addition of
Primary Protectors is not sufficient protection in order to connect these interfaces metallically to
OSP wiring. Statement 7005
Warning
Cisco NCS 2000 Series Hardware Installation Guide
384
Installing the Cisco NCS 2015 Door and Other Modules
VoIP or UDC
