Step 10
Return to your originating procedure (NTP).
DLP-L63 Provisioning PPM and Port for the TNC,TNCE, and TNCS Cards
This task provisions a PPM and port on a TNC,
TNCE, and TNCS cards. PPMs are created to support
the OSC function.
Purpose
NoneTools/Equipment
DLP-G46 Log into CTCPrerequisite Procedures
As neededRequired/As Needed
Onsite or remoteOnsite/Remote
NoneSecurity Level
Procedure
Step 1
In node view (single-shelf mode) or shelf view (multishelf view), double-click the TNC, TNCE, and TNCS
cards where you want to provision PPM and port settings.
Step 2
Click the Provisioning > Pluggable Port Modules tabs.
Step 3
In the Pluggable Port Modules area, click Create. The Create PPM dialog box appears.
Step 4
In the Create PPM dialog box, complete the following:
• PPM—Choose 1 or 2 from the PPM drop-down list.
• PPM Type—Displays the PPM associated with the chosen PPM in the above step.
Step 5
Click OK. The newly created PPM appears in the Pluggable Port Modules area. The row in the Pluggable
Port Modules area becomes white when the PPM is inserted and the Actual Equipment Type column lists the
name of PPM.
Step 6
In the Pluggable Ports area, click Create. The Create Port dialog box appears.
Step 7
In the Create Ports dialog box, complete the following:
• Port—Choose the port you want to configure from the Port drop-down list.
• Port Type—Choose the port type, such as OC-3, FE, or ONE-GE from the Port Type drop-down list.
OC-3 can be configured only on PPM port 1. FE and ONE-GE can be configured on both the ports.Note
Cisco NCS 2000 Series Hardware Installation Guide
404
Installing and Configuring the Control Card
DLP-L63 Provisioning PPM and Port for the TNC,TNCE, and TNCS Cards
