Procedure
Step 1
To power up the node, insert the fuse into the fuse position according to site practice. The fuse rating must
not exceed 20A.
Step 2
If the NCS 2006 does not power up, check the voltage at the power source using a voltmeter. The voltage
should be 100 to 240 VAC +/-10 percent.
Step 3
Return to your originating procedure (NTP).
DLP-L22 Turning On and Verifying DC Office Power on the NCS 2006 Shelf
This task turns on the power and verifies correct
power and returns on the NCS 2006 shelf.
Purpose
VoltmeterTools/Equipment
•
NTP-L2 Mounting the Brackets in ANSI
Configuration , on page 163.
•
NTP-L5 Opening and Removing the Standard
Door of the NCS 2006 Shelf , on page 252.
•
Connect the chassis to the office ground. For
detailed instructions on how to ground the
chassis, see the Electrostatic Discharge and
Grounding Guide for Cisco NCS 2000 Series .
•
DLP-L19 Connecting Office Power (DC) to the
NCS 2006 Shelf ( Only), on page 209
•
DLP-L20 Connecting Office Power (DC) to the
NCS 2006 Shelf (ETSI Only), on page 213
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Do not apply power to the shelf until you complete all the installation steps.Caution
Cisco NCS 2000 Series Hardware Installation Guide
218
Connecting Power and Ground
DLP-L22 Turning On and Verifying DC Office Power on the NCS 2006 Shelf
