The NCS2006-AC supports the same specifications as the 15454-M6-AC2.Note
DC Power Specifications
The following table lists power specifications of the DC power modules for the NCS 2006 shelf.
Table 25: NCS 2006 DC Power Specifications
Maximum LoadInput Voltage
Range
External Fuse
Rating
CurrentNominal VoltageRatingDC Power
Module
1440 W
40.5 to 57.6
VDC
40 Amp30 Amp
48 VDC
30 AmpNCS 2006-DC
50 to 72 VDC
24 Amp
60 VDC
960 W
40.5 to 57.6
VDC
30 Amp20 Amp
48 VDC
20 AmpNCS2006-DC20
50 to 72 VDC
16 Amp
60 VDC
1920 W
40.5 to 57.6
VDC
60 Amp40 Amp-48 VDC40 AmpNCS2006-DC40
50 to 72 VDC
32 Amp-60 VDC
When the NCS 2006 shelf is powered at 60 VDC (nominal), only these cards can be installed: TNC,
OPT-AMP-C, OPT-AMP-17-C, OPT-EDFA-17, OPT-EDFA-24, 17 SMR9 FS, 24 SMR9 FS, 34 SMR9
FS, SMR20 FS, SMR20 FS CV, 12-AD-FS, 16-AD-FS, 100GS-CK-LC, and MR-MXP cards, and the
NCS2006-ECU-60 card.
Note
When you use the 60V DC power module for NCS 2006, you must go to CTC (shelf-view) Provisioning
> General > Power Monitor and set the following threshold values:
ELWBATVG (Extreme Low Battery Voltage)=-50 Vdc
LWBATVG (Low Battery Voltage)=-50 Vdc
HIBATVG (High Battery Voltage)=-72 Vdc
EHIBATVG (Extreme High Battery Voltage)=-72 Vdc
NCS2006-DC, NCS2006-DC20, and NCS 2006-DC40 shelf power consumption (configuration
dependent):
130 W with NCS2006-FTA Fan Tray, LCD, and ECU module
Cisco NCS 2000 Series Hardware Installation Guide
470
Hardware Specifications
System Power
