“NTP-G15 Install the Common Control Cards” in the
“Cisco ONS 15454 Hardware Installation Guide”.
“DLP-G371 Install the Ethernet Adapter Panel” in the
“Cisco ONS 15454 Hardware Installation Guide”.
Prerequisite Procedures
As neededRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
To connect the MS-ISC-100T cards to the node controller shelf and set up protection, complete the following
substeps (see the figure below).
a) Using the 5.9 in. (0.15 m) CAT-5 LAN cable, plug one connector into the NC port of the MS-ISC-100T
card located on the left side of the node controller shelf (Slots 1 to 6) and plug the other connector into
the front panel (RJ-45 connector) of the TCC3 card in Slot 7.
b) Using the 5.9 in. (0.15 m) CAT-5 LAN cable, plug one connector into the NC port of the MS-ISC-100T
card located on the right side of the node controller shelf (Slots 12 to 17) and the other end into the front
panel (RJ-45 connector) of the TCC3 card in Slot 11.
c) Using the 19.69 in. (0.5 m) CAT-5 LAN cable, plug one connector into the PRT port of the MS-ISC-100T
card located on the left side of the node controller shelf (Slots 1 to 6) and plug the other connector into
the PRT port of the MS-ISC-100T card located on the right side of the node controller shelf (Slots 12 to
17).
d) Plug the nine connectors on one end of the EAP cable into the two DCN ports and the seven subtending
shelf controller (SSC) ports of the MS-ISC-100T card located on the left side of the node controller shelf
(Slots 1 to 6). Plug the other end of the EAP cable into the multishelf port on the left EAP.
Cisco NCS 2000 Series Hardware Installation Guide
416
Multishelf Management
NTP-L64 Connect the ONS 15454 Node Controller to an MS-ISC-100T Card
