Worst Controller
Card Slot (#8)
Flow, CFM
Worst Line Card
Slot (#7) Flow,
CFM
Deflector
Configuration
Case
18.412.716.812.2Only InletETSI Front to
Side
14.710.618.713.4Inlet and OutletANSI Front to
Rear
19.714.120.714.8Only InletANSI Front to
Side
Bulk Chassis Flow, CFMDeflector ConfigurationCase
13500 RPM9600 RPM
295.6215.3No deflectorsSide to Side
135.897.7Inlet and OutletETSI Front to Rear
258.6187.7Only InletETSI Front to Side
166.9120.5Inlet and OutletANSI Front to Rear
268.6193.5Only InletANSI Front to Side
Cisco NCS 2000 Series Hardware Installation Guide
162
Installing the Air Flow Regulator
Air Flow Performance of NCS 2006
