#2 Phillips Dynamometric screwdriver
•
Medium slot-head screwdriver
•
Small slot-head screwdriver
•
ETSI only:
◦
Six M6 x 20 pan-head Phillips mounting
screws
•
ANSI only:
◦
Six #12-24 x 3/4 pan-head Phillips
mounting screws
Tools/Equipment
DLP-L62 Unpacking and Verifying the Shelf , on
page 20
DLP-L63 Inspecting the Shelf, on page 22
Prerequisite Procedures
RequiredRequired/As Needed
OnsiteOnsite/Remote
NoneSecurity Level
Procedure
Complete the necessary task as applicable:
•
DLP-L5 Mounting the Brackets on the NCS 2006 Shelf for ETSI Rack Configuration, on page 176
•
DLP-L6 Mounting the Air Deflectors (Front-to-Front) on the NCS 2006 Shelf for ETSI Rack
Configuration, on page 177
•
DLP-L7 Mounting the Bracket with Air Deflectors (Front-to-Back) on the NCS 2006 Shelf for ETSI
Rack Configuration, on page 179
•
DLP-L8 Mounting the Bracket with Air Deflectors (Front-to-Top) on the NCS 2006 Shelf for ETSI
Rack Configuration, on page 182
Stop. You have completed this procedure.
Cisco NCS 2000 Series Hardware Installation Guide
175
Mounting the Brackets on NCS 2006 Shelf
NTP-L46 Mounting the Brackets in ETSI Configuration
