Cisco NCS 2006 User Manual

OnsiteOnsite/Remote
NoneSecurity Level
The NCS 2006 requires a minimum of 10.4-inches (265 mm) vertical rack space. To ensure that the
mounting is secure, use two to three M6 mounting screws on each side of the shelf. A shelf should be
mounted at the bottom of the rack if it is the only unit in the rack.
Note
Procedure
Step 1
Verify that the proper fuse and alarm panel has been installed in the top mounting space. If a fuse and alarm
panel is not present, you must install one according to manufacturer instructions:
•
For a DC power supply, the fuse rating must not exceed 40A.
•
For an AC power supply, the fuse rating must not exceed 10A, 15A, or 20A. For North America, the
branch circuit protection must be rated 20A. The overcurrent/short circuit protection must be in accordance
with local and national electrical codes.
Step 2
Ensure that the shelf is mounted on the appropriate rack equipment:
•
23-inches (584.2 mm) or 19-inches (482.6 mm) for racks.
•
600 x 600-mm (23.6 x 23.6-inch) or 600 x 300-mm (23.6 x 11.8-inch) for ETSI racks.
Diagram 1 of the figure below shows the NCS 2006 shelf mounted on an rack in the middle position using
19-inch mounting brackets.
Cisco NCS 2000 Series Hardware Installation Guide
192
Mounting the Cisco NCS 2006 Shelf
DLP-L9 Mounting the NCS 2006 Shelf on a Rack (One Person)
