The
single
ground
lug
must
be
a
dual-hole
type,
UL
Listed,
CSA
certified
and
rated
to
accept
the
#4
A
WG
cable.
The
grounding
lug
must
be
assembled
on
the
chassis
with
two
screws
and
washers.
(See
the
figure
below).
Figure 188: Ground Lug on the NCS 2015 DC Shelf
W
asher
2
Ground
lug
1
Screw
3
Cisco NCS 2000 Series Hardware Installation Guide
329
Connecting Power and Ground
Power and Ground
356
358
