The NCS 2015 for ETSI has the following system timing specifications:
•
Stratum 3, per ITU-T G.813
•
Free running accuracy: +/- 4.6 ppm
•
Holdover stability: 3.7 exp -7 per day, including temperature (< 255 slips in first 24 hours)
•
Reference: External BITS, line, internal
System Power
The following table lists power specifications for the NCS 2015 shelf.
Table 28: Cisco NCS 2015 Power Specifications
Power Redundancy (N+N)
Up to four power modules can be installed. This allows support
for 1+0, 1+1, 2+0, and 2+2 power redundancy.
AC
Up to four power modules can be installed. This allows support
for 3+1, 2+2, 2+1, and 1+1 power redundancy and A and B battery
plant dual feeds redundancy.
DC
AC Input
200 to 240 VAC (range 180 to 264 VAC)Nominal input voltage
50/60 Hz (range 47 to 63 Hz)Nominal line frequency
30-A (North America) dedicated branch circuit
30-A (International) dedicated branch circuit
Recommended AC service
DC Input
–48 VDC or –60 VDC(tolerance range: –40.5 to –72 VDC)
Nominal input voltage
36 A max at –48 VDC28.8 A max per feed at –60 VDC42.7 A
at –40 VDC (maximum)
Input current
You can configure the power redundancy mode of an NCS 2015 chassis using CTC or TL1 commands. For
more information, see the section, “Power Redundancy” in the chapter, “Maintaining the Node” in the Cisco
NCS 2000 Series Network Configuration Guide, Release 10.x.x .
Cisco NCS 2000 Series Hardware Installation Guide
475
Hardware Specifications
System Power
