2000 ft/min (10 m/s) under typical conditions 27°C4000 ft/min
(20 m/s) at maximum speed.
Software controls the speed of the fans based on
measurements from the chassis thermal sensors.
Note
Air velocity
Fan speed 6300 RPM, temperature 80°F (27°C):70.7 dB-modular
configuration power
Sound power level (DC power)
Dimensions
The NCS 2015 shelf assembly has these dimensions:
•
Height: 24.44 inches (620.776 mm)
•
Width: 17.67 inches (448.81 mm)
•
Depth: 11.10 inches (281.94 mm)
•
Weight:
◦
Empty chassis: 69.225 pounds (31.4 kg)
◦
Chassis with ancillary units and line cards: 99.20 pounds (45 kg)
Cisco NCS 2000 Series Hardware Installation Guide
477
Hardware Specifications
Dimensions
