c) Tighten the screws to a torque value of 11.5 in-lb (1.3 N-m).
Figure 15: Installing the left vertical air plenum
Step 4
Install the vertical air plenum to the right of the horizontal air plenum. Follow step 3a to 3c.
Figure 16: Installing the right vertical air plenum
Cisco NCS 2000 Series Hardware Installation Guide
32
Installing the Air Flow Regulator
DLP-L65 Installing Air Plenum for NCS 2002 Shelf in ANSI 19-inch Configuration
