Step 6
Install the vertical plenum to the right of the horizontal air plenum. Follow step 5a to 5c.
Figure 21: Installing the right vertical air plenum
Step 7
Install ANSI 19-inch standard brackets on both sides of the chassis in front position. See DLP-L35 Mounting
the 19-inch Brackets on the NCS 2002 Shelf for ANSI Rack Configuration, on page 46.
Step 8
Install the NCS 2002 empty chassis below the horizontal plenum.
Figure 22: Installing the NCS 2002 chassis below the horizontal air plenum
Cisco NCS 2000 Series Hardware Installation Guide
37
Installing the Air Flow Regulator
DLP-L69 Installing Air Plenum in NCS 2002 Shelf for ANSI 23-inch Configuration
