Time and SNTP Commands
Extreme Networks EAS 100-24t Switch CLI Manual
115
Each command is listed, in detail, in the following sections.
Example usage:
To configure SNTP settings:
config sntp
Purpose Used to setup SNTP service.
Syntax config sntp {primary <ipaddr> | secondary <ipaddr> | poll-interval <int
30-99999>} (1)
Description This command is used to configure SNTP service from an SNTP server.
SNTP must be enabled for this command to function (See enable sntp).
Parameters primary - This is the primary server from which the SNTP information will be
taken.
<ipaddr> - The IP address of the primary server.
secondary - This is the secondary server the SNTP information will be taken
from in the event the primary server is unavailable.
<ipaddr> - The IP address for the secondary server.
poll-interval <int 30-99999> - This is the interval between requests for updated
SNTP information. The polling interval ranges from 30 to 99999 seconds.
Restrictions Only Administrator-level users can issue this command. SNTP service must
be enabled for this command to function (enable sntp).
#config sntp primary 10.1.1.1 secondary 10.1.1.2 poll-interval 30
Command: config sntp primary 10.1.1.1 secondary 10.1.1.2 poll-interval 30
Success.
#
show sntp
Purpose Used to display the SNTP information.
Syntax show sntp
Description This command is used to display SNTP settings information.
Parameters None.
Restrictions None.
