Multiple Spanning Tree Protocol (MSTP) Commands
Extreme Networks EAS 100-24t Switch CLI Manual
161
Example usage:
To configure STP with path cost auto, hellotime 2 seconds, migration enable, and state enable for ports 1
to 2:.
Example usage:
To create a spanning tree instance 2:
#config stp ports 1-2 externalCost auto hellotime 2 migrate yes state enable
Command: config stp ports 1-2 externalCost auto hellotime 2 migrate yes state enable
#
create stp instance_id
Purpose Used to create a STP instance ID for MSTP.
Syntax create stp instance_id <value 1-4>
Description This command allows the user to create a STP instance ID for the Multiple
Spanning Tree Protocol. There are five STP instances on the switch (one
internal CIST, unchangeable) and the user may create up to four instance IDs
for the switch.
NOTE: Switches in the same spanning tree region having the same STP
instance_id must be mapped identically, and have the same configuration
revision_level number and the same name.
Parameters <value 1-4> - Enter a value between 1 and 4 to identify the Spanning Tree
instance on the switch.
Restrictions Only Administrator-level users can issue this command.
#create stp instance_id 2
Command: create stp instance_id 2
Success.
#
config stp instance_id
Purpose Used to add or delete an STP instance ID.
Syntax config stp instance_id <value 1-4> [add_vlan | remove_vlan] <vidlist>
Description This command is used to map VIDs (VLAN IDs) to previously configured STP
instances on the switch by creating an instance_id. A STP instance may have
multiple members with the same MSTP configuration. There is no limit to the
number of STP regions in a network but each region only supports a
maximum of five spanning tree instances (one unchangeable default entry).
VIDs can belong to only one spanning tree instance at a time.
