Multiple Spanning Tree Protocol (MSTP) Commands
Extreme Networks EAS 100-24t Switch CLI Manual
155
Example usage:
To display the router ports:
Multiple Spanning Tree Protocol (MSTP) Commands
This switch supports three versions of the Spanning Tree Protocol; 802.1D STP, 802.1w Rapid STP and
802.1s MSTP. Multiple Spanning Tree Protocol, or MSTP, is a standard defined by the IEEE community
that allows multiple VLANs to be mapped to a single spanning tree instance, which will provide
multiple pathways across the network. Therefore, these MSTP configurations will balance the traffic
load, preventing wide scale disruptions when a single spanning tree instance fails. This will allow for
faster convergences of new topologies for the failed instance. Frames designated for these VLANs will
be processed quickly and completely throughout interconnected bridges utilizing any of the three
spanning tree protocols (STP, RSTP or MSTP). This protocol will also tag BPDU packets so receiving
devices can distinguish spanning tree instances, spanning tree regions and the VLANs associated with
them. These instances will be classified by an instance_id. MSTP will connect multiple spanning trees
with a Common and Internal Spanning Tree (CIST). The CIST will automatically determine each MSTP
Parameters <vlan_name 32> - The name of the VLAN on which the router port resides to
view information for.
<vidlist> - The VIDs of the configured routers to view information for.
static - Displays router ports that have been statically configured.
dynamic - Displays router ports that have been dynamically configured.
forbidden - Displays forbidden router ports that have been statically
configured.
If no parameters are specified, the system will display all currently configured
router ports on the switch.
Restrictions None.
# show mld_snooping mrouter_ports
Command: show mld_snooping mrouter_ports
VLAN Name : default
Static Router Port : 1-10
Dynamic Router Port :
Forbidden Router Port :
VLAN Name : vlan2
Static Router Port :
Dynamic Router Port :
Forbidden Router Port :
Total Entries : 2
#
show mld_snooping mrouter_ports
