Link Aggregation Commands
Extreme Networks EAS 100-24t Switch CLI Manual
141
Example usage:
To display Link Aggregation configuration:
Example usage:
To configure LACP port mode settings:
#show link_aggregation
Command: show link_aggregation
Link Aggregation Algorithm = MAC-source-dest
Group ID : 1
Type: : Static
Master Port : 1
Member Port : 1-4
Active Port :
Status : Disabled
Flooding Port : 0
Total Entries : 1
#
config lacp_ports
Purpose Used to configure settings for LACP compliant ports.
Syntax config lacp_ports <portlist> mode [active | passive]
Description This command is used to configure ports that have been previously
designated as LACP ports (see create link_aggregation).
Parameters <portlist> - Specifies a port or range of ports to be configured.
mode – Select the mode to determine if LACP ports will process LACP control
frames.
active – Active LACP ports are capable of processing and sending LACP
control frames. This allows LACP compliant devices to negotiate the
aggregated link so the group may be changed dynamically as needs require.
In order to utilize the ability to change an aggregated port group, that is, to
add or subtract ports from the group, at least one of the participating devices
must designate LACP ports as active. Both devices must support LACP.
passive – LACP ports that are designated as passive cannot process LACP
control frames. In order to allow the linked port group to negotiate adjustments
and make changes dynamically, at one end of the connection must have
“active” LACP ports (see above).
Restrictions Only Administrator-level users can issue this command.
#config lacp_ports 1-12 mode active
Command: config lacp_ports 1-12 mode active
Success.
#
