262 HEIDENHAIN Technical Manual MANUALplus 620
Wire colors of adapter cable ID 633 608-xx for X112/X113 to TS or TT:
X112/X113 on
PLB 62xx or
UEC 11x (FS)
Adapter cable 633 608-xx
Female (D-sub) Male (D-sub) Color Female (M12)
1 1 Not assigned
22Pink4
33Green5
4 4 Gray 6
5 5 Not assigned
66Blue3
77White7
8 8 Not assigned
9 9 White/Green 1
10 10 Brown/Green 2
11 11 Brown 8
12 to 15 12 to 15 Not assigned
