102 Keysight M8000 Series of BER Test Solutions User Guide
3 Quick Tour with M8070A User Interface
The M8070A System Software provides quick design analysis with the
Eye Diagram capability. The Eye Diagram allows a quick check for the
DUT’s signal output, and determines the signal quality. The eye
contour lines display the measured eye at a deeper BER level, for
accurate results.
For details, refer to Eye Diagram Measurement on page 525.
Utilities Menu
The Utilities menu provides the following selections:
• Script Editor - Opens the Script Editor user interface as shown in the
following figure:
