Keysight M8000 Series of BER Test Solutions User Guide 187
User Interface - M8020A Display Views 4
Create New Groups in Group View
To create a group in Group View:
•Click New Group icon available on the tool bar. This will open the
System Group Editor.
• Select the ports or locations from the left side the System Group
Editor and the preview of selected ports or locations will appear on
right side. See the following figure:
Provide a group name and
• Type a group name in the provided field and click Create. A new group
will be created under that name.
Show Function Block/Location in Groups
The Group View allows you to set the group properties either through
functional blocks or through locations in the group.
You can click icon to switch to show functional blocks in the group.
See the following figure:
