User Interface - M8020A Display Views 4
parameters while the acquisition is enabled. There is no need for large
timeouts if parameters are only set when the acquisition is stopped and
the oscilloscope is idle.
Please refer the M8000 Series Programming Guide the for details
regarding the commands listed in the following tables.
Acquisition related commands
Clock and clock reference related commands
Parameter Identifier Commands
State INF*.Common :ACQuisition:STATe <identifier>, {OFF|ON|0|1}
:ACQuisition:STATe? <identifier>
Reconfigure INF*.Common
INF*.DataIn1
:ACQuisition:REConfigure <identifier>
Bits per
Acquisition
INF*.DataIn1 :ACQuisition:BITS<identifier>,<number_of_bits>
:ACQuisition:BITS? <identifier>
Symbols per
Acquisition
INF*.DataIn1 :ACQuisition:SYMBols <identifier>,<number_of_UI>
:ACQuisition:SYMBols? <identifier>
Memory Depth INF*.Common
INF*.DataIn1
:ACQuisition:POINts[:ANALog]? <identifier>
Parameter Identifier Commands
Follow SYS CLK INF*.DataIn1 :CLOCk:TRACk[:STATe] <identifier>,{OFF|ON|0|1}
Symbol Rate INF*.DataIn1 :SENSe:SRATe[?] <identifier>,<NRf>
:SENSe:SRATe? <identifier>
External
Reference Clock
INF*.Common :TRIGger[:SOURce] <identifier>,{INTernal|REFerence}
:TRIGger:REFerence[:FREQuency] <identifier>,{REF10|REF100}
