4 User Interface - M8020A Display Views
Equalization related commands
Clock recovery related commands
Line coding related commands
Parameter Identifier Commands
State INF*.DataIn1 :INPut:EQUalization:FFEQualizer:STATe <identifier>,{OFF|ON|0|1}
:INPut:EQUalization:FFEQualizer:STATe? <identifier>
FFE Taps INF*.DataIn1 :INPut:EQUalization:FFEQualizer:NTAPs <identifier>,<number>
:INPut:EQUalization:FFEQualizer:NTAPs? <identifier>
FFE Pre Taps INF*.DataIn1 :INPut:EQUalization:FFEQualizer:NPRecursor <identifier>,<number>
:INPut:EQUalization:FFEQualizer:NPRecursor? <identifier>
Auto-set
equalizer
INF*.DataIn1 :INPut:EQUalization:FFEQualizer:TAP:AUTO <identifier>
Parameter Identifier Commands
State INF*.DataIn1 :INPut:CDR:OJTF[:STATe][?] <identifier>,{OFF|ON|0|1}
Loop Bandwidth INF*.DataIn1 :INPut:CDR:OJTF:SECond:LBANdwidth <identifier>,<NRf>
:INPut:CDR:OJTF:SECond:LBANdwidth? <identifier>
Loop Bandwidth
Divisor
INF*.DataIn1 :INPut:CDR:OJTF:SECond:LBANdwidth:DIVisor <identifier>,<NRf>
:INPut:CDR:OJTF:SECond:LBANdwidth:DIVisor? <identifier>
Damping Factor INF*.DataIn1 :INPut:CDR:OJTF:SECond:DFACtor <identifier>,<NRf>
:INPut:CDR:OJTF:SECond:DFACtor? <identifier>
Parameter Identifier Commands
Coding INF*.DataIn1 :DATA:LINecoding:VALue? <identifier>,<PAM4|NRZ>
:DATA:LINecoding:VALue <identifier>
Symbol Mapping INF*.DataIn1 :DATA:LINecoding:PAM4:MAPPing <identifier>,<NONE|GRAY|CUSTom>
:DATA:LINecoding:PAM4:MAPPing? <identifier>
Custom Symbol
Mapping
INF*.DataIn1 :DATA:LINecoding:PAM4:MAPPing:CUSTom <identifier>,<string>
:DATA:LINecoding:PAM4:MAPPing:CUSTom? <identifier>
