Keysight M8000 Series of BER Test Solutions User Guide 391
Setting up Patterns 7
You to select the pattern from the following options:
•Clock
•Pulse
•PRBS
Refer to the Table 51 on page -382 and Table 52 on page -383 for the
list of available PRBS polynomials.
• Static
•Memory
In case the Memory option is selected, a Select Memory Pattern…
button will appear.
When you click this button, the Select Pattern dialog will appear.
Once you select the pattern in Select Pattern dialog, click Apply
button to download the pattern.
