42 Keysight M8000 Series of BER Test Solutions User Guide
2 Know Your Hardware
The M8041A module has the following components.
Table 7 Insertion/Extraction and Retaining
Table 8 Front Panel LEDs
Component Description
Retaining screws The screws on both ends of the module are used to retain the module tightly inside the M9505A AXIe
Chassis slot once you have fully placed it inside the chassis. To remove the module, you first need to
loosen these screws ensuring that these screws disengage completely.
Module Insertion/Extraction
Handles
The handles on both sides of the module to insert or eject the module from the slot of the M9505A AXIe
Chassis.
Connector Name Active when... Color
Fail power-up fault condition red
Access power-up ready state green
Data In x input is overloaded red
Data Out x output is overloaded red
Data Mod In x input is active green
Ctrl In A/Ctrl In B logic level is detected green
Ctrl Out A output is active green
Clk In signal is detected green
Ref Clk In signal is detected green
Ref Clk Out output is active green
Aux In not used n/a
Clk Out output is active green
Trig Out output is active green
Clk Mod In input is active green
Sys Out A/Sys Out B output is active green
Sys Ctrl In A/Sys Ctrl In B logic level is detected green
