Keysight M8000 Series of BER Test Solutions User Guide 653
Appendix 11
PCI Express
PCI Express 2
Pattern Description
compliance_b8b10 Compliance patterns
compliance_bit Compliance patterns
test_payload_b8b10 Compliance pattern; pattern format B8B10
test_payload_bit Compliance pattern; pattern format BIT
ts1_b8b10 part of trainings sequence; pattern format B8B10
ts1_bit part of trainings sequence; pattern format BIT
ts1_skp1_b8b10 part of trainings sequence; pattern format B8B10
ts1_skp1_bit part of trainings sequence; pattern format BIT
ts1_skp_bit part of trainings sequence; pattern format BIT
ts2_b8b10 part of trainings sequence; pattern format B8B10
ts2_bit part of trainings sequence; pattern format BIT
ts2_skp_bit part of trainings sequence; pattern format BIT
ts2_skp2.b8b10 part of trainings sequence; pattern format B8B10
ts2_skp2.bit part of trainings sequence; pattern format BIT
Pattern Description
Compliance5G_b8b10
PCIe2_Compliance_b8b1
0
PCIe2_trainLB_1_bit
PCIe2_trainLB_2_bit
PCIe2_trainLB_3_bit
TrainLoopback5G_1_bit
TrainLoopback5G_2_bit
