Keysight M8000 Series of BER Test Solutions User Guide 657
Appendix 11
SAS
SATA
Pattern Description
JTPAT_b8b10 Jitter Tolerance Pattern (JTPAT) Minus
SAS_CJTPAT_Repeat_w_all_aligns_b8b10 CJTPAT framed for SAS; includes ALIGNs;
uses B8B10 format
SAS_IDLE_CJTPAT_IDLE_ALIGNO_b8b10 IDLE, CJTAPT, IDLE framed for SAS; includes
ALIGN 0; uses B8B10 format
scrambled_0-from-grex-demo-board_b8b10 Scrambled 0 pattern captured from G-Series
scope demo board; uses B8B10 format
Pattern Description
ALIGN_b8b10 Align primitive as defined in SATA standard.
COMP-long-2.6spec_b8b10 Long COMP pattern starting with negative running
disparity as defined in SATA standard version 2.6
COMP-long-framed_b8b10 Obsolete long framed COMP pattern
COMP-long_b8b10 Long COMP pattern starting with negative running
disparity as defined in SATA standard version 2.5
COMP-short-2.6spec_b8b10 Short COMP pattern starting with negative running
disparity as defined in SATA standard version 2.6
COMP-short_b8b10 Short COMP pattern as defined in SATA standard
version 2.5
Framed_COMP_20070905_2ALIGNs_n
ewLBP_92160_b8b10
Long framed COMP according to SATA standard
version 2.6 with 2 ALIGNs
Framed_COMP_20070907_2ALIGNs_o
ldLBP_92160_b8b10
Long framed COMP according to SATA standard
version 2.5 with 2 ALIGNs
HFTP_b8b10 SATA High Frequency Test Pattern
HFTP_w_align_b8b10 SATA High Frequency Test Pattern; includes ALIGNs;
uses B8B10 format
HTDP_long_b8b10 SATA long high transition density pattern
HTDP_short_b8b10 SATA long high transition density pattern
