658 Keysight M8000 Series of BER Test Solutions User Guide
11 Appendix
USB 3.0
LBPspecv2.5-short-w-align_b8b10 SATA lone bit pattern according to SATA standard
version 2.5; includes ALIGNs; uses B8B10 format
LBP_long-2.6spec_b8b10 SATA short lone bit pattern according to SATA
standard version 2.6
LBP_long_b8b10 SATA long lone bit pattern according to SATA standard
version 2.5
LBP_short-2.6spec_b8b10 SATA long lone bit pattern according to SATA standard
version 2.6
LBP_short_b8b10 SATA short lone bit pattern according to SATA
standard version 2.5
LFSCP_long_b8b10 SATA long low frequency spectral content pattern
LFSCP_short_b8b10 SATA short low frequency spectral content pattern
LTDP_long_b8b10 SATA long low transition density pattern
LTDP_short_b8b10 SATA short low transition density pattern
MFTP_b8b10 SATA mid frequency test pattern
SSOP_long_b8b10 SATA short simultaneous switching outputs pattern
starting
SSOP_short_b8b10 SATA short simultaneous switching outputs pattern
starting
k28.5_b8b10 K28.5 symbols; uses B8B10 format
Pattern Description
Clock_bit clk/2 pattern; uses BIT format
D0_SCRAMBLED_b8b10 scrambled D0; uses B8B10 format
K25_K27_2SKP_b8b10 debug pattern; uses B8B10 format
K285_D0_b8b10 debug pattern; uses B8B10 format
LFPS_BURST_1us_IDLE_9us_bit part of trainings sequence; uses BIT format
LFPS_IDLE_9us_BURST_1us_bit part of trainings sequence; uses BIT format
Pattern Description
