Keysight Technologies M8000 Series User Manual

Keysight M8000 Series of BER Test Solutions User Guide 659
Appendix 11
XAUI
LFPS_TRIGGER_bit part of trainings sequence; uses BIT format
TS1_31_2SKP_b8b10 part of trainings sequence; uses B8B10 format
TS1_31_4SKP_b8b10 part of trainings sequence; uses B8B10 format
TS2_2SKP_b8b10 part of trainings sequence; uses B8B10 format
TS2_4SKP_b8b10 part of trainings sequence; uses B8B10 format
TSEQ_b8b10 part of trainings sequence; uses B8B10 format
BRST_2SKP_b8b10 part of trainings sequence; uses B8B10 format
BRST_4SKP_b8b10 part of trainings sequence; uses B8B10 format
COMMA_2SKP_b8b10 debug pattern; uses B8B10 format
COMMA_4SKP_b8b10 debug pattern; uses B8B10 format
CP0_2SKP_SCRAMBLED_b8b10 CP0 compliance pattern containing SKP doubles;
pre-scrambled; uses B8B10 format
CP0_2SKP_for_SER_b8b10 CP0 compliance pattern containing SKP doubles;
pre-scrambled; uses B8B10 format
CP0_4SKP_for_SER_b8b10 CP0 compliance pattern containing SKP doubles;
pre-scrambled; uses B8B10 format
Clock16_bit clk/16; uses BIT format
Clock8_bit clk/8; uses BIT format
Clock4_bit clk/4; uses BIT format
Clock2_bit clk/2; uses BIT format
Pattern Description
CJPAT_bit CJTPAT; uses BIT format
CRPAT_b8b10 CRPAT; uses B8B10 format
CRPAT_bit CRPAT; uses BIT format
Pattern Description
