Page 100 Data entry/Programming Group 7
Release R1.12 en JET2 neo
7.2.2.2.2 Menu structure
Figure 48
Explorer (Menu structure)
1 – Buttons <Tools>
4 – Pop-up window <Filter>
2 – Selection window <Internal memory>
5 – Button <Clone internal memory>
3 – Selection window <USB-Stick>
6 – Button <Close>
 Buttons <Tools> (1): With the buttons you can select the several tools of the explorer.
 Selection window <Internal memory> (2): In the selection window the data or the
filtered data of the internal memory of the JET2neo are displayed.
 Selection window <USB-Stick> (3): In the selection window the data or the filtered
data of the external data carrier are displayed.
Annotation: A selection window is activated by clicking on the display area of the
window. The active window is marked by a turquoise border.
 Filter (4): With the pop-up window you can select the several data fields which should
be displayed or processed. If a filter has been used, only the accordant data is shown
in the two selection windows.
The following filters are available:
 All
 Jobs
 Fonts
 Graphics
 Joblists
3
5
4
1
active
selection window
6
2
