Leibinger JET2neo - Figure 86 - System Info (Save Info File); Save Info File

Group 7 Data entry/Programming Page 147
JET2 neo Release R1.12 en
7.2.4.1.1 Save info file
The displayed system information can be swapped out to an external memory device
(USB-stick).
Proceeding:
 Plug an USB-Stick in the USB-access (1) of the device.
 Press the button <Export> (2).
 The data is saved on the connected medium and the Message (3), that the process
has been carried is faded in.
The memory happens with the designation „info_LJ2neo-(“serial number of the
printer”).txt“.
 Finally confirm the message with the button <OK ()> (4).
If no storage medium (memory device) is connected, the Message (5) is
faded in. Confirm the message with the button <OK ()> (6). Connect a
memory device and repeat the complete process.
Figure 86
Save info file
2
1
5
4
3
4
