Leibinger JET2neo - Figure 90 - Menu Hydraulic-;Printhead-;Spec. Functions

Page 152 Data entry/Programming Group 7
Release R1.12 en JET2 neo
By closing the menu all changes are reset to the normal/fully automatic
operating condition!
If the menu closes an accordant message (6) is faded in which can confirm
or cancel the quitting.
Figure 90
Menu “Hydraulic-/Printhead-/Spec. functions”
1 – Button <Hydraulic/Printhead>
5 – Button <Close>
2 – Menu <Hydraulic/Printhead/Spec.>
6 – Message <Close menu>
3 – Register cards
7 – Button <OK ()>
4 – Button <Quick Off>
4
1
3
7
6
2
5
