Page 122 Data entry/Programming Group 7
Release R1.12 en JET2 neo
Bounce time delay:
Describes a predefined safety time. That means if an input is switched, the signal
will be only valid after this safety time.
At the LEIBINGER JET2neo you can switch on or off this safety time.
Figure 67
Bounce time delay
Bounce time delay
Advantages
Disadvantages
off
Faster change of jobs
No safety for bouncing signals
afterwards
on
High safety for bouncing
signals afterwards
Slower change of jobs
Figure 68
Select encoder interface
Bounce time delay is switched off
Bounce time delay is switched on
1 – Register card <Interfaces>
2 – Pop-up window <Encoder settings>
3 – Control box <Jobselect debounce off>
Time (t)
defined
status
t
Safety
(disengageable)
Switching of
inputs
Input- Signal gauge )
1
2
3
