Leibinger JET2neo - Remove Shift Times; Figure 144 - Print Elements (Shift Code Remove)

Group 8 Job editor Page 235
JET2 neo Release R1.12 en
 Carry out the inputs („002“ and „003“) accordingly for the further shift code fields.
 Press the button ()> (13) to take over the input and to close the menu or press the
button <Close> (14) to leave the menu without saving the inputs.
 In the menu <Job editor> (15) the fix text followed by the applied shift code are
displayed.
Note:
Displayed is the shift code which is currently valid
(as in the example the late shift „002“).
8.6.4.3 Remove shift times
Shift times that are no longer needed are deleted.
Proceeding:
 Mark the shift time to be deleted (1) in the management window (2).
 Press the button <Remove> (3). The shift time is deleted.
Figure 144
Print elements (Shift code remove)
1 – marked shift time
2 – Management window
3 – Button <Remove>
3
1
2
