Group 4 Technical data Page 26
Release R1.12en JET2 neo
4. Technical data
4.1 Housings, dimensions, weights
Cabinet :
Stainless steel
Width 400 mm, depth 295 mm, height 430 mm
Weight: 17 kg
Print head:
Stainless steel cabinet
Length (total) 212 mm, diameter 43 mm
Length of the print head lead 3 m
Weight: 1,5 kg
Any fitting position, also for overhead conveyor applications
Figure 3
Dimensions
Protection class:
IP 54
400 mm
295 mm
430 mm
212 mm
 43 mm
