Leibinger JET2neo - Example of Use; Safety Instructions; Figure 14 Example of Use

Page 54 Operation – Elements and procedures Group 6
Release R1.12 en JET2 neo
6.2.7 Example of use
Figure 14
Example of use
1 – Product
3 – Encoder
5 – Print head
2 – Conveyor belt
4 – Sensor
6.3 Safety instructions
Inflammable (Risk of fire)!
Combustible gases and liquids cause serious burns. Sources of
ignition must be kept away from the print head and the device!
Risk of injury!
Ink escapes from the head aperture. Spraying of ink into the eyes
can cause blindness. Eye protection is necessary!
3
5
2
1
= Direction of conveyance
4
