Page 198 Job editor Group 8
Release R1.12 en JET2 neo
8.5.2.2.1 PrintGo-source
(Print start query)
To inform the JET2neo when a printing text should be printed, a so called Print-Go signal
is required. It can be generated internally, depending on the set PrintGo-parameters, as
well as externally by a sensor (e.g. light barrier, product sensor etc.).
This sensor is called as Print-Go source.
 Extern: If this function is activated an external sensor has to be connected to the
interface X5 of the LEIBINGER JET2neo.
Pos. flank:
Neg. flank:
Note: The product sensor 24V can be NPN- or PNP-connected.
 Intern:
If this function is activated a print is generated depending on the set PrintGo-
parameters.
Note: A connected sensor is not inquired.
Figure 125
PrintGo-source (Print start query)
Start
Start
