Group 6 Operation – Elements and procedures Page 53
JET2 neo Release R1.12 en
6.2.6 Summary of the individual procedures
Figure 13
Creation of a character
X
X+1
Character height created
by drop deflection
Drop brake-off point
Character „E“ build with a
7 x 5 matrix
Rel. movement direction of the
description area
Gutter
Deflector plate
Charge electrode with deflector electrode
Nozzle (jet)
Oscillator
Character width created by the rel. movement of the description area
