Leibinger JET2neo - Figure 37 - Graphic Editor (Structure and Call Up)

Page 88 Data entry/Programming Group 7
Release R1.12 en JET2 neo
Further information about the organization, character, editing and
viewing tools of the Graphic Editor can be found in the following
chapters!
Figure 37
Graphic editor (Structure and call up)
1 – Button <Graphic editor>
7 – Display tools
2 – Menu <Graphic editor>
8 – Display <Coordinates>
3 – Organization tools
9 – Display <Activities to carry out>
4 – Drawing tools
10 – Button <OK ()>
5 – Edit tools
11 – Button <Close>
6 – Input field <Graphic>
1
9
2
3
6
8
7
11
10
4
5
